TP LEEG SMP858-TST-S105GGF-T1R1-FC-6NTSSA03-Q1 ( 0-5 BAR)
1,00 1,00 1.0 ARS
Advantage

• Dual diaphragm overload structure can easily cope with high overload tests.

• 355° rotation display module, friendly button parameters operation function.
• Accurate filling fluid technology eliminates effects of temperature and static pressure.
• High strength metal electrical protection housing meets the most rigorous environmental application.
• Strong transient voltage resistance to protect terminal module.
• External three buttons menu function enables site operation and does not affect the degree of electrical protection, in a safer and more convenient manner.
• Beautiful appearance, fully show the fashion sense of science and technology.
• Perfect match between internationally leading technology and Chinese smart manufacture.



Features

• Measuring range: -100kPa ~ 1MPa

• Output signal: 4-20mA, 4-20mA+HART, customer
• Reference accuracy: ±0.1% URL
• Stability: ±0.1% URL/ 36 months
• Media temperature: -40-120℃
• Electrical connection: Aluminum-alloy terminal, 2 cable entry M20*1.5(F), red body, white cover
• Diaphragm: SUS316L, Hastelloy C, Tantalum, SUS316 + PTFE cover, Tantalum + PTFE cover, Hastelloy C + PTFE cover...
• Process connection: DN50PN10 flange, DN25PN10 flange
• Protection class: IP67
• Approvals: CSA, NEPSI, CE, RoHS



Industry application

• Petroleum industry
TP LEEG SMP858-DST
1,00 1,00 1.0 ARS
Advantage

• High-stability pressure sensor.

• Originally patented fully-sealed, fully-isolated the pressure sensor.
• Accurate filling fluid technology, eliminates effects of temperature and static pressure.
• Dual diaphragm overload structure, can easily cope with high overload tests.
• ASIC and SMT signal transmitting module.
• Powerful 24 ADC achieves high precision and quick response.
• 355° rotation display module, friendly button parameters operation function.
• Strong transient voltage resistance to protect terminal module.



Features

• Measuring range: 10kPa-1MPa

• Output signal: 4-20mA, 4~20mA/HART, customer
• Reference accuracy: ±0.1% URL, optional ±0.075% URL
• Media temperature: -40-120℃
• Measuring medium: pressure, level, differential pressure, density, interface, flow
• Protection class: IP67
• Diaphragm material: SUS316L, Hastelloy C
• Stability: ±0.2% URL/5 years
• Process connection: DN50PN10, DN80PN10, DN100PN10
• Approvals: CSA, NEPSI, CE, RoHS



Industry application

• Process control system

• Petroleum industry
• Chemical industry
TP LEEG 10 BAR DMP305X-TST-S105GSSF-T1R2-HC-6R01
1,00 1,00 1.0 ARS
Features

• Measuring range: 1kPa-10MPa

• Output signal: 4-20mA, 4-20mA+HART, customer
• Reference accuracy: ±0.075% URL, optional ±0.05% URL
• Stability: ±0.2% URL/ years
• Diaphragm: SUS316L, Hastelloy C
• Media temperature: -40-120℃
• Protection class: IP67
• Process connection: M20*1.5(M), G1/2(M), G1/4 (M), 1/2-14NPT(M), etc
• Approvals: CSA, ATEX, IECEx, NEPSI, RoHS, CE



Industry application

• Process control system

• Petroleum industry
• Chemical industry
• Electric power
TP LEEG DMP305X-DST
1,00 1,00 1.0 ARS
Transmisor de presión diferencial marca LEEG
TP LEEG SMP858-TST-S104GGF-T1R2-HC-6NTSSH01-/Q1/E1 (0-500 MBAR)
1,00 1,00 1.0 ARS
Advantage

• Dual diaphragm overload structure can easily cope with high overload tests.

• 355° rotation display module, friendly button parameters operation function.
• Accurate filling fluid technology eliminates effects of temperature and static pressure.
• High strength metal electrical protection housing meets the most rigorous environmental application.
• Strong transient voltage resistance to protect terminal module.
• External three buttons menu function enables site operation and does not affect the degree of electrical protection, in a safer and more convenient manner.
• Beautiful appearance, fully show the fashion sense of science and technology.
• Perfect match between internationally leading technology and Chinese smart manufacture.



Features

• Measuring range: -100kPa ~ 1MPa

• Output signal: 4-20mA, 4-20mA+HART, customer
• Reference accuracy: ±0.1% URL
• Stability: ±0.1% URL/ 36 months
• Media temperature: -40-120℃
• Electrical connection: Aluminum-alloy terminal, 2 cable entry M20*1.5(F), red body, white cover
• Diaphragm: SUS316L, Hastelloy C, Tantalum, SUS316 + PTFE cover, Tantalum + PTFE cover, Hastelloy C + PTFE cover...
• Process connection: DN50PN10 flange, DN25PN10 flange
• Protection class: IP67
• Approvals: CSA, NEPSI, CE, RoHS



Industry application

• Petroleum industry
TRANSMISOR PRESION DIFERENCIAL LEEG 250 KPA DMP305X-DST-S254DSSP-T1R2-HC-H1-/A2/B3/Q1/E1
1,00 1,00 1.0 ARS
Range: 0-250 kPa
Accuracy: 0.075%
Signal: 4-20 mA+HART
Proc. Connection: 1/2 NPT female, 316ss
With LCD display, pipe mounting bracket
TP LEEG 40 KPA DMP305X-DST-S403DSSP-T1R2-HC-H1
1,00 1,00 1.0 ARS
Features

• Measuring range: 1kPa-10MPa

• Output signal: 4-20mA, 4-20mA+HART, customer
• Reference accuracy: ±0.075% URL, optional ±0.05% URL
• Stability: ±0.2% URL/ years
• Diaphragm: SUS316L, Hastelloy C
• Media temperature: -40-120℃
• Protection class: IP67
• Process connection: M20*1.5(M), G1/2(M), G1/4 (M), 1/2-14NPT(M), etc
• Approvals: CSA, ATEX, IECEx, NEPSI, RoHS, CE



Industry application

• Process control system

• Petroleum industry
• Chemical industry
• Electric power
TP LEEG 250 KPA DMP305X-DST-S254DSSP-T1R2-HC-H1
1,00 1,00 1.0 ARS
Features

• Measuring range: 1kPa-10MPa

• Output signal: 4-20mA, 4-20mA+HART, customer
• Reference accuracy: ±0.075% URL, optional ±0.05% URL
• Stability: ±0.2% URL/ years
• Diaphragm: SUS316L, Hastelloy C
• Media temperature: -40-120℃
• Protection class: IP67
• Process connection: M20*1.5(M), G1/2(M), G1/4 (M), 1/2-14NPT(M), etc
• Approvals: CSA, ATEX, IECEx, NEPSI, RoHS, CE



Industry application

• Process control system

• Petroleum industry
• Chemical industry
• Electric power
